BSK Zephyr Plus Single Room Heat Recovery Unit (100mm)

SKU : BSK-Zephyr-Plus

Overview

The BSK Zephyr Plus is a high-performance decentralized heat recovery ventilation unit designed to provide continuous fresh air to individual rooms without the need for a traditional centralised ducted ventilation system.

€446,28 EUR Excl. VAT: €371,90 EUR

Low stock

For warranty information, please refer to the manufacturer’s warranty policy or contact them directly.

Any questions? Reach out to our team

Download Files

View full details

Description

Product Part Number

BSK-Zephyr-Plus

Product Overview

The BSK Zephyr Plus is a high-performance decentralized heat recovery ventilation unit designed to provide continuous fresh air to individual rooms without the need for a traditional centralised ducted ventilation system.

Ideal for residential properties, renovations, apartments and light commercial applications, the Zephyr Plus combines heat recovery, low-energy EC fan operation and intelligent humidity and temperature sensing within a compact through-wall unit.

During operation, stale indoor air is extracted through the unit while the ceramic heat exchanger captures and stores thermal energy from the outgoing air. The airflow then reverses, drawing fresh outdoor air back through the ceramic core where the stored heat is transferred to the incoming air. This alternating process helps maintain a comfortable indoor temperature while reducing the heat losses associated with conventional extract ventilation.

With airflow rates of up to 100 m³/h, thermal efficiency of up to 90%, four fan speed settings and very low power consumption, the Zephyr Plus provides an energy-efficient solution for improving indoor air quality and controlling excess moisture.

Key Features

Decentralized heat recovery ventilation
Suitable for residential and light commercial applications
No central ductwork required
Airflow up to 100 m³/h
Heat recovery efficiency up to 90%
Four operating speeds including Night Mode
Low-energy operation from just 1.1 W
Integrated digital temperature and humidity sensor
Ceramic regenerative heat exchanger
Alternating supply and extract airflow
Helps reduce heat loss while introducing fresh outdoor air
Supports improved indoor air quality
Helps control excess indoor humidity
Low sound levels, with sound pressure from 13.7 dBA at 1 metre
2 × G3 filters
Suitable for operating temperatures from -25°C to +40°C
230V / 50Hz electrical supply

Technical Specification

Technical Specification	Night Mode	Speed I	Speed II	Speed III
Airflow	25 m³/h	50 m³/h	75 m³/h	100 m³/h
Power Consumption	1.1 W	1.4 W	2.2 W	3.9 W
Sound Power	24.7 dBA	28.1 dBA	35.3 dBA	43 dBA
Sound Pressure at 1m	13.7 dBA	17.1 dBA	24.3 dBA	32 dBA
Sound Pressure at 3m	4.2 dBA	7.6 dBA	14.8 dBA	22.5 dBA

Additional Technical Information

Specification	Details
Electrical Connection	230V / 50Hz
Thermal Efficiency	Up to 90%
Sensor Type	Digital temperature and humidity sensor
Filters	2 × G3 filters
Operating Temperature	-25°C to +40°C
Ventilation Type	Decentralized / single-room heat recovery
Heat Exchanger	Regenerative ceramic heat exchanger
Maximum Airflow	100 m³/h
Maximum Power Consumption	3.9 W

How the Zephyr Plus Works

The Zephyr Plus operates using an alternating airflow cycle. During the extract cycle, warm stale air from inside the room passes through the ceramic heat exchanger, transferring heat energy into the ceramic core.

The fan then reverses direction and draws fresh outdoor air through the same heat exchanger. The stored thermal energy is transferred to the incoming fresh air before it enters the room.

This regenerative heat recovery process allows the Zephyr Plus to continuously refresh indoor air while recovering up to 90% of the heat that would otherwise be lost through conventional ventilation.
